DWXT40B20R-L
DWXT40B20R-L

DCS-DWVC | DCS-DWVD

Digital Wireless Chairman | Delegate Voting Unit (MIC not included)

The wireless conference system unit combines advanced technology with user-friendly design, offering effortless setup and maximum efficiency for modern meetings. Powered by standard Wi-Fi technology, it seamlessly integrates with existing networks, ensuring zero interference by selecting from multiple frequency points. Its elegant design with anti-scratch and dustproof glass, maintaining a flawless appearance even after extensive use.

Features

FUNCTIONS

  •         The system delivers uncompressed audio with high fidelity across a frequency range of 20Hz to 20kHz using professional-grade microphones.
  •       It employs full-digital transmission and processing technology to ensure superior sound quality.
  •      The system uses 128-bit digital encryption, WPA2 secure connections, MAC address filtering, and SSL security to prevent unauthorized access and eavesdropping.
  •      It supports simultaneous operation of up to six wireless microphones for seamless audio performance.
  •      The system includes RS485, RS232, and IP communication interfaces for transmitting PELCO and VISCA protocols.
  •      It enables automatic camera tracking when integrated with compatible cameras and video switchers.
  •       A built-in high-fidelity speaker automatically mutes when the microphone is activated, preventing audio feedback and ensuring a smooth audio experience.

Tech Specification

Model DCS-DWVC | DCS-DWVD
Power 100V / 240V AC
power consumption 12W
Maximum power consumption 150W
Frequency Response    20Hz ~ 20KHz
Noise ratio 96dBA
Total harmonic distortion  0.05%
Channel Crosstalk 85dB
Dynamic range 94dB
Ethernet control RJ45 connected to PC
Dimensions (mm 483L x 260W x43.6H
Weight 3kg
